• Lifting capacity: 10.000 kg
• Capacity at maximum height: 7.000 kg
• Lifting height: 9,52 m
• Reach: 5,05 m
• Engine: Deutz TCD 3.6 L4 – stage V
• Rated power: 100 kW (134 hp) 2.200 rpm
• Number of gears: 2/2
• Hydraulic system: 350 bar (Load Sensing)
• Length: 5,66 m
• Width: 2,55 m
• Ground clearance: 370 mm
• Unladen weight: 13.200 kg
• Travel speed: 40 km/h
• Climate control as standard: Yes
• Automatic attachment recognition: Yes
• Reversable fan drive: Yes

• 2006/42/CE : EU Machinery Directive
• EN 13000 : concerning standards for mobile cranes
• ROPS/FOPS Level 2 : relating to the standards for protective structures
• 2016/1628 : EU regulation on the emissions of  Stage V engines
• EN 1459-2 : concerning standards for slewing variable-reach trucks

The HTH 10.10 telescopic handler is ideal for moving large, bulky loads in complete safety. Able to lift up to 10 tonnes, it is compatible with a wide range of accessories, making it extremely versatile. Equipped with an RFID system which provides automatic recognition of the various attachments used, this telescopic handler is able to meet a wide range of applications in heavy industry. Its four-wheel drive system, three maneuvering modes and high ground clearance makes it highly maneuverable on all terrain types.
